The MasterVolt GMDSS Remote Panel provides remote monitoring for battery and charger status, with GMDSS safety system compatibility.

The MasterVolt GMDSS Remote Panel is a must-have for any seafarer. This remote panel allows for easy monitoring of battery voltage and current for 12/24 V DC systems, and also includes safety functions for the globally recognised GMDSS system. With a clear LCD display and status LED's, this panel ensures efficient and safe operation on board. The potential-free switch over contacts for DC voltage alarm, charger alarm, and AC mains alarm provide additional safety measures. The included shunt and user manual make installation and use simple and hassle-free.

Features

  • Remote monitoring for battery and charger status
  • GMDSS system compatibility
  • LCD display and status LED's
  • Potential-free switch over contacts for alarms
  • Includes shunt and user's manual for easy installation and use

(MV70400050)

Function Monitoring of battery and charger status (12/24 V DC)
Supply voltage 8-32 V DC
Safe compass distance 1 meter (standard), 0.3 mm (steering)
Current 110 mA (12 V), 65 mA (24 V)
Alarms DC voltage, charger, and AC mains
Dimensions 180 x 65 x 40 mm (cut-out: 168 x 53 mm)
Shunt dimensions M8, 84 x 44 x 44 mm
Weight 400 gr (excl. shunt), 1 kg (incl. shunt)
Voltage range 0-62.7 V DC (0.1 V resolution)
Voltage accuracy ± 0.2 V (12 V), ± 0.4 V (24 V)
Shunt specification 500 A / 50 mV
SKU MV70400050
Barcode # 70400050
Brand Mastervolt
Shipping Weight 1.0000kg
